On rounding of intervals

CuInterval makes use of the built-in CUDA math functions which use round-to-nearest-even. Since some math functions are not fully accurate up to machine presicion, they do not conform to IEEE 754, we have to perform additional outward rounding to cover the worst-cases of the specified maximum ulp-error of an intrinsic function.

Note

Outward rounding applies rounding towards -∞ for lower bounds and rounding towards +∞ for upper bounds. Since most math functions in CUDA do not have corresponing operations that round towards ±∞, we make use of nextafter(x, ±∞). Sometimes, we know that the function is bounded (e.g., $\exp(x) > 0$). In those cases, we apply nextafter(x, 0) or similar tighter outward roundings whenever possible.

The CUDA math functions use round-to-nearest-even and thus pick the even floating point number if the number would land exactly between two floating point values, otherwise it picks the nearest available value between two floating point values.

We use the same maximum ulp error terminology as CUDA: The maximum difference (in ulps) of the correctly rounded operation using round-to-nearest-ties-to-even and the obtained values from the implemented operation.

If the intrinsic function has a reported max. error of 1 ulp, then the resulting interval output will have a max. error of 2 ulps compared to the correctly rounded operation and 2.5 ulps compared to the real analytic value. To see why, let’s look at all the scenarios that could be possible:

We denote the absolute error from the true floating point value by $\Delta\text{ulp}$. A $\Delta\text{ulp}$ of 0.5 indicates that the value is 0.5 ulps away from the real analytic value because it is not representable as, e.g., a 64-bit floating point number.

Conservative Rounding

This is a rather conservative form of rounding. Consider upper-bounding for the scenario in the bottom-right picture: It assumes that even if the output value is halfway between an odd value -1 (below) and an even value 0 (above) that it could end up landing at 1 (above) as the reference of CUDA does not specify anything beyond the max. error for most functions. The function output could, however, also land on -1, in which case we must round upwards once. Since we do not make any assumption as to when either scenario happens, rounding upwards is always performed, leading to a maximum error of 2 ulps to the correctly rounded operation and 2.5 ulps to the real analytic value.

So,

$$\begin{aligned} \bigl|\inf(F(X)) - \inf(\hat{F}(X))\bigr| &\leq 2.5\ \text{ulps} \\ \bigl|\sup(F(X)) - \sup(\hat{F}(X))\bigr| &\leq 2.5\ \text{ulps} \end{aligned}$$

is what we guarantee in this case, where $F$ is the analytic function and $\hat{F}$ represents the implemented interval operation.

Inclusion of real values

By default, no rigorous rounding is performed in the sense that it is guaranteed, that the true analytic result is contained in the resulting interval. It is only assured that the corresponding floating point representation of that real value is contained. It would require an additional rounding, which in the vast majority of scenarios would lead to unnecessary rounding. In the above scenario a max. ulp error of 3.5 ulps could occur.
